MSI MEG Z790 ACE (E-ATX | Support 12th, 13th & 14th Gen Intel Processor | Thunderbolt4 | Wi-Fi 6E | DDR5 | Gen5 M.2 Support) | Availability: In Stock

  • Intel 12th and 13th Gen, E-ATX Motherboard, 3x PCI-E X 16 Gen 4.0/Lightening Gen 5.0 with steel armor supports up to 128GB/s bandwidth
  • 1x Type-C DisplayPort, 2x Thunderbolt4, 2x Mini DisplayPort
  • 4x RAM Slot (Max. 192GB, 5000 to 7800+ MHz), 5x M.2 (4x Gen4 & 1x Gen5)
  • 6x SATA, RAID 0/1/5/10, 1x USB 3.2 Gen2 Type-C (1x Back), 7x USB 3.2 Gen2 Type-A (7x Back)
  • 4x USB 3.2 Gen2 (Back), 4x USB 3.2 Gen1 (4x Internal Connector), 4x USB 2.0 (Internal Connector)
  •  2x Intel® 2.5Gbps LAN controller, Intel® Wi-Fi 6E (Wi-Fi 6E + Bluetooth 5.3)
  • Realtek® ALC4082 Codec  + ESS ES9280AQ Combo 7.1 Channel HD Audio
  •  Supports S/PDIF output, (Audio Boost 5, Core Boost, Memory Boost Technology), Supports AMD Crossfire, 5x M.2 Shield Frozr, Mustic Light

 0 Ratings 0 Answered Questions

Brand:MSI |

Youtube : MSI MEG Z790 ACE (E-ATX | Support 12th, 13th & 14th Gen Intel Processor | Thunderbolt4 | Wi-Fi 6E | DDR5 | Gen5 M.2 Support)

Share Buttons

Rs. 106,200 Rs. 111,510 4.76%

Quantity

Delivery Options

All over Nepal

Home Delivery

2 to 4 Days Days

Shipping Price : Rs. 20/kg
Cash on Delivery Available
Return

within 7 Days days easy return Change of mind is not applicable

1

CPU SUPPORT Supports 12th, 13th & 14th Gen Intel® Core™ Processors for LGA 1700 Socket
CHIPSET Intel® Z790
MEMORY (RAM)

4x DDR5 UDIMM, Maximum Memory Capacity 192GB
Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7800+ MHz
• 1DPC 2R Max speed up to 6600+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5600+ MHz

Supports Intel® XMP3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memory

ONBOARD GRAPHICS

1x Type-C DisplayPort
Supports a maximum resolution of 4K @ 60Hz

*Available only on processors featuring integrated graphic

EXPANSION SLOTS

3x PCI-E x16 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

*PCI_E1 slot will run at x8 speed when installing device in the PCI_E2 slot or M2_4 slot.
**M2_4 slot will be unavailable when installing device in the PCI_E2 slot

MULTI-GPU AMD MULTI-GPU Support
STORAGE

5x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices
M.2_4 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280 devices
M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 22110/2280/2260 devices
6x SATA 6Gb/s

*M2_4 slot will be unavailable when installing in the PCI_E2 slot.
**SATA7 will be unavailable when installing M.2 SATA SSD in the M2_5 slot.

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices

*SATA_A1_A2 do not support RAID function.

LAN 2x Intel® 2.5Gbps LAN
WIRELESS / BLUETOOTH Intel® Wi-Fi 6E, Supports Bluetooth® 5.3
USB

4x USB 2.0 (Internal)
4x USB 3.2 Gen 1 5Gbps Type-A (Internal)
7x USB 3.2 Gen 1 10Gbps Type-A (Rear)
1x USB 3.2 Gen 2 10Gbps Type-C (Rear)
2x USB 3.2 Gen 2x2 20Gbps Type-C (Internal)

*To achieve 60W PD fast charging for JUSB6, the PD_PWR1 connector needs to be connected to the power supply unit.
**JUSB6 doesn’t support USB 2.0 device

AUDIO Realtek® ALC4080 Codec
7.1-Channel USB High Performance Audio
Supports up to 32-Bit/384 kHz playback on front panel
BACK I / O PORTS 1x Clear CMOS Button
1x Flash BIOS Button
2x 2.5G LAN
2x Thunderbolt 4 40Gbps (Type-C)
Wi-Fi / Bluetooth
Audio Connectors
Smart Button
1x USB 3.2 Gen 2 10Gbps (Type-C Display port)
6x USB 3.2 Gen 2 10Gbps (Type-A)
2x Mini DisplayPort Input (for Thunderbolt passthrough)
1x Optical S/PDIF-Out
LED FEATURE 1x EZ LED Control switch
4x EZ Debug LED
1x 2-Digit Debug Code LED
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
FORM FACTOR E-ATX
304.8mm x 277mm
